Praxis Brodium MTN Pedal
Tax included.
Description
BRODIUM
New Name, familiar shape.
Praxis seamlessly merges tradition with modernity, bringing back the beloved Podium shaped pedal. With blessings from Gamut's founders, this revival isn't just about its return; it signifies our dedication to honoring the history of this iconic pedal design.
DESIGN
With meticulous attention to detail, we have preserved the essence of the original Podium pedal so cherished by riders, while incorporating a variety of updates for today's trail riding
LOW PROFILE
With three Enduro bearings and an Igus bushing, this design ensures a low-profile configuration, enabling smooth rotation on a heat-treated 4140 chromoly axle
DETAILS
With its svelte shape and concave platform to grip your foot, the details stand out. Custom shaped pins that are based on M4 thread allows full customization.
| SPECIFICATIONS | |
|---|---|
| INSTRUCTIONS | ⚠️ VIEW MANUAL HERE |
| BUY THIS IF : | You want a performance alloy flat pedal with a serious pedigree. Works with both Alloy and Carbon cranks. |
| BODY | Forged and CNC | 6061-T6 Aluminum Low profile - 3mm Concave platform 12 stainless steel black pins per side with pre-applied Loctite |
| FOOTPRINT | 14mm - Height 115mm - Length 112mm - Width |
| AXLE | Forged Heat-treated 4140 chromoly spindle 8mm Allen for easy install/removal |
| PINS | - 48 stainless steel rear-loading pins installed/included - M4 threaded so other M4 grub pins also compatible - 3mm Allen for install/removal - Allows you to customize your pin layout with a total of 12 pins per side |
| WEIGHT | 399g pair with Steel pins |
| BEARINGS BUSHINGS |
3 High-Grade Sealed Cartridge Enduro Bearings per pedal 1 Igus Bushing per pedal |
| REBUILD KIT | SOLD SEPARATELY - Axle Kit - Bearing/Bushing Rebuild Kit |
| EXTRA | Included extra : - 12 M4 pins - 24 pin spacers for customizing pin height |
| RIDER NOTES | - Torque the pedal axle to the Crank 35-40Nm. - Pedal Washers : are not required but may use up to 2mm pedal washers per side. - Crank Boots : Compatible with most rubber crank protector/boots in the market. |
Praxis Brodium MTN Pedal
Sale price$205.00
